Product identity

Warnings

Keep for reference: read carefully.

Always remember to be careful not to use the product improperly, considering its designated functions.

When the product is no longer used, do not abandon it, but take it to a suitable public waste collection facility.

Do not rest objects or weights on the open flap doors of the storage units.

To maintain the quality and finish of the surface, it is advisable to use protective articles (e.g. placemats or trivets) under objects that could scratched it.

This product sheet complies with the legal obligations pursuant to the "Consumer Code" Decree n. 206 dated 6/9/2005 and the "Actuation Regulation" Decree n. 101 dated 8/2/1997.

Materials

Lateral sides, central sides, central and upper crosspieces, baseboards
aluminium extrusions

Tops, shaped tops, partitions, backs, open projecting elements, projecting elements for flap door, projecting elements for drawer, multipurpose top
wood particles panel, MDF wood fibre panel

Back panels for TV/Home office
panel in cellulose fibre impregnated with thermosetting resins, subjected to high pressure processing

Glass top
tempered glass

Flap door for projecting elements, drawer fronts for projecting elements
glass, wood particles panel, MDF wood fibre panel

Internal shelves for projecting elements with flap door, internal shelves for projecting elements with drawer
tempered glass

Cable flap
aluminium

Frames
steel

LED lighting system
Strip LED HE, 12V DC 1.65 W 5000K

EU power supply unit
input voltage 220-240V 50Hz, output voltage 12V DC, maximum wattage 30W

US power supply unit
input voltage 110-120V 50Hz, output voltage 12V DC, maximum wattage 30W

Touch-LED switch
operating voltage 12 V DC

Maintenance

Wood - Painting

For weekly maintenance, dust the surface with a dry cloth.
For dried dirt, use a well-squeezed out cloth, damp with warm water.
For greasy or oily dirt, use a damp sponge and dish washing detergent, and then wipe with a well-squeezed out cloth damp with warm water.
Warning! Apply the detergent directly on the damp sponge, and never on directly on the furniture.
Do not exert excessive pressure and always follow the grain on wood furniture.
Note that if you press or rub too hard, surfaces can become 'polished'.
Avoid using abrasives and products containing solvents, ammonia and/or alcohol.
Make sure to dry the surfaces completely after washing.

Glass

Dust the entire surface carefully to remove any dust (use a soft white cloth).
We advise using normal commercial products for cleaning delicate surfaces.
Rub the surface to be cleaned gently without concentrating just on the area requiring attention: start instead with a larger section and gradually work your way towards the area in the middle.
That way, you will avoid rings or scratches forming, which may be produced if you apply too much pressure to the surface.
Never use solvents or abrasive detergents.

Aluminium - Steel

We advise using normal commercial products for cleaning delicate surfaces and/or warm water and neutral soap.
Never use abrasives or products containing solvents, ammonia and/or alcohol.
Make sure to dry the surfaces completely after washing.

Led

The luminaire is classified as EEE (electrical and electronic equipment) and must be disposed of in compliance with regulations.
Individual LED in the bar cannot be replaced. If one malfunctions, it is necessary to replace the entire bar.
Clean the luminaire only when disconnected from the power mains.
Clean only with a dry cloth.
